Digital Test Solutions

BitifEye and Eurofins are approved as a joined MIPI Independent Test Lab. Through this collaboration products can be tested for conformance on M-PHY, UFS (based on the UniPro test mode), C-PHY, D-PHY, CSI or DSI. Successfully passed products can be uploaded at the MIPI Product Registry Submission site.

Arbitrary waveform generators (AWGs), Bit-Error Ratio Testers (BERTs), oscilloscopes and network analyzers are the instruments of choice when performing physical layer compliance (also: conformance) test of digital high-speed interfaces like PCI Express, USB, HDMI or MIPI. But, on their own, the instruments are insufficient to ensure the complete validation of your products. A full, automated compliance test solution requires more; it comprises software, test point access adapters (test fixtures), additional accessories such as cables, and switching.
BitifEye provides the products you need to turn a standard instrument – or a combination of standard instruments – into a complete compliance test solution for specific interface standards. BitifEye’s products are fully compatible with AWGs, BERTs, oscilloscopes and network analyzers from Keysight Technologies (formerly Agilent Technologies Test and Measurement group) and other suppliers.
With software, switching and accessories from BitifEye you can efficiently use and extend the capabilities of your instruments, so you can be assured that your products meet the latest digital bus standards.

PCI Express Test Set Up

e.g. for Add-in Cards or Chip Sets

  • Infiniium Oscilloscope and J-BERT M8020A
  • PCI 1.0a, 1.1, 2.0 and 3.0 supported

USB Test Set Up

Infiniium Oscilloscope and J-BERT M8020A

  • USB 2.0 and 3.0 supported
  • USB 3.1 and Type C support

SATA Test Set Up

Infiniium Oscilloscope and J-BERT M8020A

  • J-BERT BIST and internal or external FER Detector
  • SATA UTD 1.4 supported

Thunderbolt Test Set Up

J-BERT M8020A and Infiniium Oscilloscope

  • TBT Gen3 supported

SD UHS-II Test Set Up

J-BERT M8020A and Infiniium Oscilloscope

  • CTS 1.0 supported

HDMI Test Set Up

Infiniium Oscilloscope and TMDS Signal Generator M8195A

  • HDMI CTS 1.4b and 2.0 supported
  • HDMI Protocol Test with Quantum Data 980

DisplayPort Test Set Up

HDMI TMDS Signal Generator J-BERT M8020A and Infiniium Oscilloscope

  • DP 1.2b and eDP 1.4 supported
  • ALT Mode and Type C supported

MHL Test Set Up

Subset of HDMI test configuration

  • MHL CTS 1.4, 2.2 and 3.3 supported
  • MHL CTS 4: contact BitifEye

MIPI M-PHY Test Set Up

J-BERT M8020A and Infiniium Oscilloscope

  • CTS 2.0, 3.0, 3.1 supported
  • UFS / UniPro CTM, Macro PHY support for UniPro, LLI, DigRF v4, SSIC

MIPI C-PHY Test Set Up

e.g. Cell Phone Processors to Display and Camera

  • Signal Gen. M8190A or M8195A AWG and Infiniium Oscilloscope
  • CTS 1.0 supported

MIPI D-PHY Test Set Up

e.g. Cell Phone Processors to Display and Camera

  • Signal Gen. M8190A or M8195A AWG and Infiniium Oscilloscope
  • CTS 1.0, 1.1, 1.2 supported

MIPI M-PHY UFS / UniPro

M8020A J-BERT and BIT-3000 DSGA

  • UFS / UniPro supported

USB Cable and Connector Test

ENA / TDR and ECAL with BitifEye Switch System

  • Type C support SuperSpeed USB and SuperSpeed USB 10 GBps
  • USB 3.1 Gen2, USB 3.1 Gen1, 2.0, 3.0

HDMI Cable & Connector Test

ENA / TDR and ECAL with BitifEye Switch System

  • HDMI 1.4 supported

To learn how BitifEye’s products can help you prove your conformance to the latest digital bus standards, contact us at:...
